High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3

МОК: 1
цена: Customized
Стандартная упаковка: Plywood Case
Срок доставки: 30 Days
Метод оплаты: T/T
Пропускная способность: 20 sets per month
Подробности Информация
Описание продукта
Подробная информация
Place of Origin
China
Фирменное наименование
Sinuo
Сертификация
Calibration Certificate(Cost Additional )
Model Number
SN555
Impact Weight:
9.1 ± 0.1 kg, meets various standards
Drop Height:
1–1000 mm, ±3 mm precision
Structure:
Dual-column guided free-fall
Safety:
Magnetic relief door, limit switch, safety hook
Window:
300×300×10 mm explosion-proof glass
Monitoring:
≥4MP HD camera, 1TB storage, remote access
Lighting:
LED light
Interface:
Touchscreen, ≤1 mm accuracy
Выделить:

Battery Heavy Impact Test Machine

,

High Safety Battery Heavy Impact Test Machine

Описание продукта



High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3







Product information:



This equipment is designed to evaluate the safety performance of lithium-ion batteries by simulating mechanical impacts under various conditions of mass, height, and contact area. The test ensures that under standard-defined impact scenarios, the battery does not catch fire or explode.



Test Principle:



A test sample is placed on a flat surface with a 15.8 mm diameter rod positioned horizontally across the center. A 9.1 ± 0.1 kg weight is dropped from a height of 610 ± 25 mm directly onto the rod. The sample is observed for six hours post-impact. Each sample is used once only.

Acceptance Criteria: The battery must not ignite or explode.



Technical parameters:



Drop weight 9.1±0.1kg
Drop height 1–1000 mm (vertically guided free fall)
Display accuracy ≤1mm
Height accuracy ±3mm
Display mode Touch screen
Diameter of horizontal bar 15.8±0.2 mm (This steel bar is placed vertically in the middle of the battery, and a heavy object falls on the steel bar, and the steel bar remains parallel to the bottom surface of the square battery;)
Test space W300 X D500 X H1000mm
Inner box material SUS 201# stainless steel (1.2mm thickness, total thickness of reinforcement and outer box is 80mm)
Outer box material Cold mixed plate baking (1.5mm thickness)
Exhaust vent 150mm, located above the back of the box
Observation Window Single door, open observation window, cold handle door lock
Window size 300*300*10mm thick tempered explosion-proof glass)
Lifting Mechanism Electric lifting
Impact Surfaces Steel plate (top and bottom)
Machine Dimensions W750XD700XH1600 mm
Power AC 220V, 500W
Weight Approx. 200 kg




Others Parameter:



Lighting



The test chamber is designed with high-brightness LED lighting, making it easy to see the test status inside the test chamber

High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 0

Explosion-proof pressure relief device



It has a magnetic explosion-proof pressure relief function. That is, the protective box automatically absorbs the pressure relief door (specification: 200*200mm) after being hit by a shock wave. When a strong airflow hits, the pressure relief door automatically opens and closes to reduce the impact of the explosion.

High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 1

Smoke exhaust



Smoke exhaust fan, exhaust port diameter 100mm

High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 2

Protection device



Limit protection switch, safety hook (located at the impact upper plate crossbeam, plays a safety protection role)

High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 3

Monitoring



The test area is equipped with a high-definition video surveillance system. It can be remotely controlled to ensure data accuracy. The picture is clear, with a pixel of ≥ 4 million pixels. The storage device is equipped with a 1T hard disk + Lenovo monitor.

High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 4

Touchscreen interface



 High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 5
Installation site

The ground is flat and well ventilated

No strong vibration around the equipment

No strong electromagnetic field around the equipment

No flammable, explosive, corrosive substances and dust around the equipment

Proper use and maintenance space is left around the equipment, as shown in the following figure:

High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 6
Power supply conditions

Power supply: AC220V single-phase two-wire + protective ground wire

Voltage fluctuation range: AC (220±20)V

Frequency fluctuation range: (50±0.5)Hz

Power capacity: about 500W

Maximum current: 3A

Power switch: 5A




Equipment Features:



1. The standard weight is 9.1Kg and the diameter is 15.8mm (which can meet different standards at the same time).

2. Encoder displays the height. Intelligent control is adjustable from 0 to 1000mm (very convenient for customers to use).

3. The double-column design allows the weight to fall freely and effectively prevents safety problems.

4. The 9.1kg or 10kg weight falls from a certain height (610mm or 1000mm) onto the sample, without bias, to prevent secondary impact on the battery surface.

5. Equipped with exhaust vents (to facilitate customers to exhaust the smoke generated during battery testing outside the test room).

6. Double-layer explosion-proof tempered glass window.



High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 7High-Safety Battery Heavy Impact Test Machine Impact Weight 9.1KG UN38.3 8
